Specification

• Image Sensor:                       VOx Uncooled Focal Plane Arrays
• Resolution:                       160×120
• Pixel Interval:                       17μm
• Response Waveband:                       8μm to 14μm
• NETD:                       Less than 40 mK (@25°C,F#=1.1)
• Focal Length:                       6.2mm
• IFO:                       V2.74 mrad
• Aperture:                       F1.1
• Field Of View:                       25.0° × 18.7° (H × V)
• Min. Focusing Distance:                       0.6 m

• Image Sensor:                       1/2.7" Progressive Scan CMOS
• Resolution:                       2688×1520, 4MP
• Min. Illumination:                       Color: 0.0176 Lux @ (F2.25, AGC ON), B/W: 0.0035 Lux @ (F2.25, AGC ON)
• Field Of View:                       39.42° × 22.14°(H × V)
• Focal Length:                       8mm
• Shutter Speed:                       1s to 1/100,000s
• White Balance:                       Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Daylight Lamp/Sodium Lamp
• Day & Night Mode:                       IR cut filter with auto switch
• WDR:                       120 dB

• IR Distance:                       Up to 40 m
• IR Intensity And Angle:                       Automatically adjusted

• Bi-Spectrum Image Fusion:                       Fusion view of thermal view and overlaid details of the optical channel
• Picture In Picture:                       Combines details of thermal and optical image PIP, overlay thermal image on optical image

• VCA:                       Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules totally.
• Temperature Measurement:                       Support 3 temperature measurement rule types, 21 rules (10 points, 10 areas, and 1 line).
• Temperature Range:                       From -20°C to +150°C (-4°F ~ +302°F)
• Temperature Accuracy:                       ± 8 °C (±14.4 °F)
• Fire Detection:                       Support dynamic fire point detection, up to 10 fire points detectable.
• Smoking Detection:                       Support

• Main Stream:                       Thermal: 25fps(1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240);Optical: 50Hz: 25fps (2688 × 1520), 25fps (1920 × 1080), 25fps (1280 × 720);Optical: 60Hz: 30fps (2688 × 1520), 30fps (1920 × 1080), 30fps (1280 × 720)
• Sub Stream:                       Thermal: 25fps(704 × 576, 352 × 288, 320 × 240);Optical: 50Hz: 25fps (704 × 576), 25fps (352 × 288), 25fps (176 × 144);Optical: 60Hz: 30fps (704 × 480), 30fps (352 × 240), 30fps (176 × 120)
• Video Compression:                       H.264 (Baseline/Main/High Profile) /MJPEG/H.265
• Audio Compression:                       G .711u/G.711a/G.722.1/MP2L2/G.726/PCM
• Protocols:                       TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
• API:                       ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK
• Security:                       Password protection, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP over HTTPS
• Simultaneous Live View:                       Up to 20

• Client:                       iVMS-4200, Hik-Connect
• Web Browser:                       Plug-in required: IE8-IE11, Chrome 41-44, Firefox 30.0-51
• Alarm Input:                       2-ch inputs (0-5 VDC)
• Alarm Output:                       2-ch relay outputs, alarm response actions configurable
• Alarm Action:                       SD recording/Relay output/Smart capture/FTP upload/Email linkage
• Audio Input:                       1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10%
• Audio Output:                       Linear Level; Impedance: 600Ω
• Communication Interface:                       1, RJ45 10M/100M Self-adaptive Ethernet interface. 1, RS-485 interface
• On-Board Storage:                       Built-in MicroSD card slot, supporting MicroSD/SDHC/SDXC card (up to 256 G), supports manual/alarm recording

• Web Client Language:                       32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
• User/Host Level:                       Up to 32 users, 3 levels: Administrator, Operator, User
• Power:                       PoE (802.3af, class 3), 42.5 V to 57 V, 0.14 A to 0.22 A;DC 12V, 0.65A
• Power Consumption:                       PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, max. 8 W 12 VDC ± 20%: 0.65 A, max. 7.5 W
• Work Temperature/Humidity:                       From -40°C to 65°C (-40°F to 149°F); Humidity: 95% or Less
• Protection Level:                       IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
• Dimension:                       358.3 mm × 113.5 mm × 115.2 mm (14.10" × 4.47" × 4.53")
• Weight:                       Approx. 1.76 kg (3.88 lb)

• Detection Range For Humans (1.8×0.5m):                       182 m
• Detection Range For Vehicles (4.0×1.4m):                       559 m
• Recognition Range For Humans (1.8×0.5m):                       46 m
• Recognition Range For Vehicles (4.0×1.4m):                       140 m
• Identification Range For Humans (1.8×0.5m):                       23 m
• Identification Range For Vehicles (4.0×1.4m):                       70 m

• VCA Range For Humans:                       42 m
• VCA Range For Vehicles:                       126 m
• Temperature Measurement Range For Object (2m×2m):                       132 m
• Temperature Measurement Range For Object (1m×1m):                       66 m
• Fire Detection Range For Object (2m×2m):                       360 m
• Fire Detection Range For Object (1m×1m):                       180 m
