3K Indoor Fixed Turret Camera – DS-2CE76K0T-EXLPF

Key Features:

• High-Resolution Imaging: 3K (2960 × 1665) CMOS sensor delivers sharp and detailed visuals.

• Excellent Low-Light Performance: 0.02 Lux @ (F2.2, AGC ON) and 0 Lux with IR for superior night imaging.

• Day/Night Functionality: True day/night with ICR (Infrared Cut Filter).

• Flexible Angle Adjustment: Pan: 0°–360°, Tilt: 0°–90°, Rotate: 0°–360°.

• Multi-Format Video Output: Switchable TVI/AHD/CVI/CVBS formats.

• Weatherproof Design: IP67-rated for reliable outdoor/indoor use.

Camera Specifications:

• Image Sensor: 3K CMOS

• Signal System: PAL/NTSC

• Shutter Speed:

  • PAL: 1/25 s to 1/50,000 s

  • NTSC: 1/30 s to 1/50,000 s

Lens:

• Lens Type: 2.8 mm or 3.6 mm fixed focal lens (M12 mount)

• Field of View (FOV):

  • 2.8 mm: Horizontal 101°, Vertical 64°, Diagonal 125°

  • 3.6 mm: Horizontal 80°, Vertical 51°, Diagonal 98°

Illumination:

• Smart IR & White Light Range: Up to 20 m (for both IR and white light)

Image & Video:

• Adjustable Parameters: Brightness, Sharpness, Smart IR

• Image Modes: STD / HIGH-SAT / HIGHLIGHT

• Wide Dynamic Range: Digital WDR

• Image Enhancement: DWDR, BLC, HLC, HLS, Global

• Frame Rates:

  • TVI: 3K @20 fps; 4 MP @25/30 fps; 1080p @25/30 fps

  • AHD: 5 MP @20 fps; 4 MP @25/30 fps

  • CVI: 4 MP @25/30 fps

  • CVBS: PAL/NTSC

• White Balance: Auto / Manual

• AGC: Supported

General:

• Material: Plastic

• Dimensions: Ø70 mm × 138.8 mm (Ø2.76" × 5.46")

• Weight: Max. 150 g (0.33 lb)

• Operating Temperature: -40 °C to 60 °C (-40 °F to 140 °F), Humidity ≤90% (non-condensing)

• Protection Level: IP67

• Communication Protocol: HIKVISION-C

• Language: English

• Power Supply: 12 VDC ±25%, Max. 4.4 W

  Recommended: Use one dedicated power adapter per camera.
