• Defend applications and data before your server is built with the new HPE Trusted Supply Chain offering.
• Supporting additional second generation Intel® Xeon® Scalable processor family offerings.
• Increased Single-Width GPU Density with up to 7 NVIDIA Tesla T4 16GB Computational Accelerators or 7 Xilinx Alveo U50 Accelerators supported in a standard-depth 2U rack form factor

• Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
• Intel® Optane™ persistent memory 100 series for HPE offers the flexibility to deploy as dense memory or fast storage and enables per-socket memory capacity of up to 3.0 TB.³
• iLO 5 security enhancements: Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor. HPE InfoSight provides cloud-based analytics to predict and prevent issues proactively.

Specifications

Processor

Processor typeIntel

Processor familyIntel® Xeon® Scalable 8100/8200 series Intel® Xeon® Scalable 6100/6200 series Intel® Xeon® Scalable 5100/5200 series Intel® Xeon® Scalable 4100/4200 series Intel® Xeon® Scalable 3100/3200 series

Processor number1 or 2

Processor core available4 to 28 core, depending on model

Processor speed3.9 GHz, maximum depending on processor

Processor cache8.25 - 38.50 MB L3, depending on processor model

Server Memory

Memory typeHPE DDR4 Smart Memory with optional Intel® Optane™ persistent memory 100 series for HPE, depending on processor model selected. Intel Optane Persistent Memory for HPE only supported on select 2nd Generation Intel Scalable Series Processors, to include: 82xx, 62xxR, 62xx, 52xxR, 52xx series processors, and the 4215R and 4215 processors.

Maximum memory3.0 TB with 128 GB DDR4, depending on processor model; 6.0 TB with HPE 512GB 2666 Persistent Memory Kit, depending on processor model

Memory slots24 DIMM slots

NVDIMM typeHPE NVDIMM-N *Only available on 1st Generation Intel® Xeon® Scalable Processors

NVDIMM rankSingle rank

NVDIMM capacity16 GB

Server Cooling

System fan featuresHot-plug redundant fans, standard

Server Expansions

Expansion slots8, for detailed descriptions reference the QuickSpecs

Server Form Factor

Form factor2U Rack

Server Controllers

Network controllerHPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on model

Storage controller1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model

Server Drives

Drive supported8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD; 2 M.2 SATA SSD standard on primary riser, depending on configuration; 6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF or 2 Dual UFF rear drive optional; 20 SFF NVMe optional; NVMe support via Express Bay will limit maximum drive capacity

Management Software

Infrastructure managementHPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional; requires licenses)

Security

SecurityOptional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0

Warranty

Warranty3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. Additional information regarding worldwide limited warranty and technical support is available at: http://h20564.www2.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at http://www.hpe.com/support

Weights and Dimensions

Weight14.76 kg (32.6 lb)

Dimensions44.55 x 73.03 x 8.74 cm (17.54 x 28.75 x 3.44 in)
