Hikvision DS-3E0106P-E/M
4 Port Fast Ethernet Unmanaged POE Switch
- 4 x 10/100Mbps PoE port, and 2 × 10/100Mbps RJ45 port.
- IEEE 802.3at/af standard for PoE ports (Max. 35 W PoE output).
- IEEE 802.3, IEEE 802.3u, and IEEE 802.3x standard.
- 6 KV surge protection for PoE ports.
- Up to 300 m long-range transmission.
- Wire-speed forwarding.
Rating:
Be the first to write a review!
- 100% genuine, brand-new stock
- Delivered across Pakistan
- Showroom: TechnoCity, Karachi
- Bulk & corporate pricing on request
More info
Hikvision DS-3E0106P-E/M overview
Hikvision DS-3E0106P-E/M - 4 Port Fast Ethernet Unmanaged POE Switch.
Key Features
- 4 x 10/100Mbps PoE port, and 2 × 10/100Mbps RJ45 port.
- IEEE 802.3at/af standard for PoE ports (Max. 35 W PoE output).
- IEEE 802.3, IEEE 802.3u, and IEEE 802.3x standard.
- 6 KV surge protection for PoE ports.
- Up to 300 m long-range transmission.
- Wire-speed forwarding.
- Store-and-forward switching.
- Solid high-strength metal shell.
Specifications
| General | |
|---|---|
| Shell | Metal material |
| Net Weight | 0.27 kg (0.60 lb) |
| Gross Weight | 0.52 kg (1.15 lb) |
| Dimensions (W × H × D) | 145 mm × 68.45 mm × 25.6 mm (5.71'' × 2.69'' × 1.01'') |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature | –40 °C to 85 °C (–40 °F to 185 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Relative Humidity | 5% to 95% (no condensation) |
| Power Supply | 48 VDC, 0.8 A |
| Installation Mode | Desk-Mounted,Wall-Mounted |
| Max. Power Consumption | 38 W |
| Power Consumption in Idle | 3 W |
| Surge Protection | 6 KV |
| Network Parameters | |
| Ports | 4 x 10/100 Mbps PoE port,2 × 10/100 Mbps RJ45 port |
| MAC Address Table | 2 K |
| Switching Capacity | 1.2 Gbps |
| Packet Forwarding Rate | 0.89 Mpps |
| Internal Cache | 768 Kbits |
| Dialing Function | |
| Long Range | Ports 1 to 4 : up to 300 m. Long range performance may vary depend on camera model or cable condition. |
| Software Function | |
| VIP Port | Ports 1 to 2: data on VIP ports is preferentially forwarded when bandwidth resources are insufficient. |
| PoE Power Supply | |
| PoE Standard | IEEE 802.3af;IEEE 802.3at |
| PoE Power Pin | 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) |
| PoE Port | PoE: Ports 1 to 4 |
| Max. Port Power | 30 W |
| PoE Power Budget | 35 W |
Specifications as published by Hikvision for model DS-3E0106P-E/M.
