BlackCopper Cat-6 UTP Dark Grey
Cat 6 Foil-Shielded Cable – Dark Grey, 400 MHz
- Bare solid copper, 23 AWG
- Aluminium/Mylar foil shield with drain wire
- Protects against EMI/RFI interference
- Tested up to 400 MHz
- For 10/100/1000 Mbps networks
- FR PVC jacket, HDPE insulation
Rating:
Be the first to write a review!
- 100% genuine, brand-new stock
- Delivered across Pakistan
- Showroom: TechnoCity, Karachi
- Bulk & corporate pricing on request
More info
BlackCopper Cat-6 UTP Dark Grey overview
BlackCopper Cat-6 UTP Dark Grey is a Cat 6 cable for indoor and outdoor use, with bare solid copper conductors and an aluminium/Mylar foil shield with drain wire that protects against noise and EMI/RFI. It is ideal for data, audio and video in 10/100/1000 Mbps networks.
Key Features
- Bare solid copper, 23 AWG
- Aluminium/Mylar foil shield with drain wire
- Protects against EMI/RFI interference
- Tested up to 400 MHz
- For 10/100/1000 Mbps networks
- FR PVC jacket, HDPE insulation
- Meets TIA-568-C.2 Cat 6, ISO/IEC 11801, UL 444, RoHS
Specifications
| General | |
|---|---|
| Brand | BlackCopper |
| Type | Cat 6 foil-shielded cable |
| Colour | Dark grey |
| Construction | |
| Conductors | Bare solid copper |
| Gauge | 23 AWG |
| Insulation | HDPE |
| Jacket | FR PVC |
| Shield | Aluminium/Mylar tape with drain wire |
| Electrical | |
| Impedance | 100 ± 15 Ω (1–250 MHz) |
| Mutual Capacitance | Max. 56 pF/m |
| Delay Skew | 536 ns/100 m max. (1–400 MHz) |
| Attenuation | 19.8 dB @100 MHz; 32.8 @250; 36.4 @300; 43.0 @400 MHz |
| NEXT | 44.3 dB @100 MHz; 38.3 @250; 37.2 @300; 35.3 @400 MHz |
| PS-NEXT | 42.3 dB @100 MHz; 36.3 @250; 35.2 @300; 33.3 @400 MHz |
| ELFEXT | 27.8 dB @100 MHz; 19.8 @250; 18.2 @300; 15.7 @400 MHz |
| ACR | 24.5 dB @100 MHz; 5.5 @250 MHz |
| Standards | |
| Compliance | TIA-568-C.2 Category 6, ISO/IEC 11801, UL 444, RoHS 2002/95/EC |
Ideal For
- Networks near electrical noise
- Data, audio and video links
- Indoor and outdoor runs
