- Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.01 Lux @(F1.6, AGC ON), 0 Lux with White Light
- Shutter TimePAL: 1/12.5 s to 1/50,000 s,NTSC: 1/15 s to 1/50,000 s
- Day & NightICR
- Angle AdjustmentPan: 0° to 360°,Tilt: 0° to 75°,Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm fixed lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 105°, vertical FOV: 59°, diagonal FOV: 127°;
3.6 mm, horizontal FOV: 87°, vertical FOV: 46°, diagonal FOV: 105°
- Lens MountM12
- Microphone
- Pickup DistanceIn a radius of up to 5 m
- Amount1
- Speaker
- Rated Power2 W
- Speaker RangeIn a radius of up to 5 m
- Illuminator
- Supplement Light Type
IR,
White Light
- Supplement Light RangeIR: Up to 40 m,White Light: Up to 40 m
- Image
- Image Settings
Anti-banding,
Brightness,
Sharpness,
Smart IR
- Frame RateTVI: 1080p @25 fps/30 fps
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)Digital WDR
- Image Enhancement
DWDR,
BLC,
HLC,
Global,
HLS
- Noise Reduction2D DNR
- White Balance
Auto,
Manual
- Audio
- Audio FunctionEcho Cancellation, AI Noise Reduction, Automatic Gain Control
- Interface
- Video Output1 HD analog output
- AlarmFlashing Light Alarm (Red & Blue)
- General
- Power12 VDC ± 25%, max.8.5 W
- MaterialMain body: Metal; Enclosure: Plastic
- DimensionØ110 mm × 102.7 mm (Ø4.33″ × 4.04″)
- WeightApprox. 385 g (0.85 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
- Approval
- ProtectionIP67
