Camera

Image Sensor

1/1.2.7ʺ Progressive Scan CMOS

Min. Illumination

Color: 0.005 Lux @ (F1.2, AGC ON), 0.0176 Lux @ (F2.25, AGC ON)

B/W: 0.001 Lux @ (F1.2, AGC ON), 0.0035 Lux @ (F2.2.5, AGC ON)

Shutter Speed

1/25 s to 1/100,000 s

Day & Night

IR Cut Filter

WDR

Digital WDR

Lens

Focal Length

2 mm fixed lens

Aperture

F2.25

FOV

Horizontal FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112°

Lens Mount

M12

IR

IR Range

Up to 6 m IR range

Wavelength

850 nm

Video

Max. Resolution

1920 × 1080

Main Stream

50Hz: 25fps (1920 × 1080, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 720)

Sub Stream

50Hz: 25fps (704 × 576, 640 × 480)

60Hz: 30fps (704 × 480, 640 × 480)

Video Compression

Main stream: H.265+ / H.265 / H.264+ / H.264

Sub stream: H.265 / H.264 / MJPEG

H.264 Type

Baseline Profile / Main Profile / High Profile

H.264+

Main stream supports

H.265 Type

Main Profile

H.265+

Main stream supports

Video Bit Rate

32 Kbps to 16 Mbps

SVC

H.265 and H.264 support

Audio

Audio Compression

G.711 / G.722.1 / G.726 / MP2L2 / PCM

Audio Bit Rate

64Kbps (G.711) / 16Kbps (G.722.1) / 16Kbps (G.726) / 32-160Kbps (MP2L2)

Environment Noise Filtering

Yes

Audio Sampling Rate

8kHz / 16kHz / 32kHz / 44.1kHz / 48kHz

Smart Feature-Set

Basic Event

Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)

People Counting

Counts people entering and exiting separately

Supports real-time uploading and uploading by statistic cycle Sends email reports on daily, weekly, monthly or annually basis

Supports target filtering by height

Linkage Method

Upload to FTP/NAS, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture

Region of Interest

4 fixed regions for main stream and sub-stream


Image Enhancement

HLC, BLC, 3D DNR, defog

Image Setting

Saturation, brightness, contrast, sharpness is adjustable by client software or web browser

Day/Night Switch

Day / Night / Auto / Schedule / Triggered by alarm input (-S)

Picture Overlay

LOGO picture can be overlaid on video with 128 × 128 24bit bmp format

Network

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS

API

ONVIF (PROFILE S, PROFILE G), ISAPI, SDK, Ehome (5.0)

Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log

User/Host

Up to 32 users. 3 user levels: administrator, operator and user

Interface

Communication Interface

1 RJ45 10M/100M Ethernet port,

-S: 1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

Audio

1 Built-in Mic

-S: 1 input (line in, two-core terminal block), 1 output (two-core terminal block), mono sound

Alarm (-S)

1 input, 1 output (max. 24 VDC, 1 A)

On-board storage

300 M eMMC storage for people counting data

General

General Function

Anti-flicker, heartbeat, mirror, password protection, watermark, IP address filter

Startup and Operating Conditions

-30 °C to +45 °C (-22 °F to +113 °F), Humidity 95% or less (non-condensing)

Storage Conditions

-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)

Power Supply

12 VDC±20%, reverse polarity protection, Φ5.5mm coaxial power plug

12 VDC, PoE (36 to 57 VDC, 802.3af), Calss3

Power Consumption

12 VDC, 0.66 A, max. 8 W, PoE (802.3 af, 36 to 57 VDC), 0.23 A to 0.14 A, max. 8.3 W

Material

Front cover: plastic, camera body: metal

Dimensions

With -V: 168 mm × 61 mm × 41 mm (6.6" × 2.4" × 1.6" )

Without -V: 168 mm × 61 mm × 36 mm (6.6" × 2.4" × 1.4")

With Package: 235 mm × 120 mm × 125 mm (9.2" × 4.7" × 4.9")

Weight

Camera: Approx. 435 g (1 lb.)

With package: 725 g (1.6 lb)

Approval

EMC

47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013,

EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015

Safety

UL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IS 13252 (Part 1): 2010+A1: 2013+A2: 2015

Environment

2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006

Protection

With -V model: IP67 (IEC 60529-2013)
