Hikvision DS-2CD1067G2H-LIU View larger

Hikvision DS-2CD1067G2H-LIU

DS-2CD1067G2H-LIU

New product

6 MP ColorVu with Smart Hybrid Light Fixed Bullet Network Camera

  • High quality imaging with 6 MP resolution
  • Support Human and Vehicle Detection
  • Smart Hybrid Light: advanced technology with long range
  • Efficient H.265+ compression technology

More details

This product is no longer in stock

Whatsapp MB WhatsApp

Rs 0

Call | Whatsapp

Karachi: +92-300-0778713 , +92-300-8265122 , +92-213-2270926 , +92-213-2270927

For Information & Quotation Email: sales@mbcommunication.com.pk

More info

Product Information:

Hikvision DS-2CD1067G2H-LIU Features and Benefits

Features:

Hikvision DS-2CD1067G2H-LIU Description

CategorySpecification
Image Sensor 1/2.4" Progressive Scan CMOS
Max. Resolution 3200 × 1800
Min. Illumination Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light
Shutter Time 1/3 s to 1/100,000 s
Day & Night IR cut filter
Angle Adjustment Pan: 0°–360°, Tilt: 0°–90°, Rotate: 0°–360°
Lens Type Fixed focal lens, 2.8 mm or 4 mm optional
Focal Length & FOV 2.8 mm: HFOV 115°, VFOV 60°, DFOV 143°4 mm: HFOV 94°, VFOV 50°, DFOV 110°
Lens Mount M12
Iris Type Fixed
Aperture F1.0
DORI 2.8 mm: D64 m, O25 m, R12 m, I6 m4 mm: D77 m, O30 m, R15 m, I7 m
Supplement Light Type IR, White Light
Light Range Up to 30 m
Smart Supplement Light Yes
IR Wavelength 850 nm
Main Stream 50Hz/60Hz: 20 fps @ 3200×1800, 2688×1520, 1920×1080, 1280×720
Sub Stream 50Hz/60Hz: 20 fps @ 1280×720, 640×480, 640×360
Video Compression Main: H.265+/H.265/H.264+/H.264Sub: H.265/H.264/MJPEG
Video Bit Rate 32 Kbps to 16 Mbps
H.264/H.265 Profile H.264: Baseline/Main/High, H.265: Main
Bit Rate Control CBR, VBR
SVC & ROI SVC (H.264/H.265), 1 ROI for main stream
Audio Type Mono sound
Audio Compression G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC
Audio Bit Rate 64 Kbps (G.711), 16 Kbps (G.722.1), 16 Kbps (G.726), 32–160 Kbps (MP2L2), 16–64 Kbps (AAC-LC)
Audio Sampling Rate 8 kHz / 16 kHz
Noise Filtering Yes
Protocols IPv4/IPv6, TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP
Simultaneous Live View Up to 6 channels
API ONVIF (Profile S/T/G for -F model), ISAPI, SDK
Users Up to 32 (Admin/Operator/User)
Security Password protection, MAC authentication, security log, watermark
Client iVMS-4200, Hik-Connect
Browser Support IE10/IE11 (plugin), Chrome 57+, Firefox 52+, Edge 89+
Image Settings Rotate, saturation, brightness, contrast, sharpness, gain, white balance
Day/Night Switch Day, Night, Auto, Schedule
WDR & SNR WDR 120 dB, SNR ≥ 52 dB
Image Enhancement BLC, HLC, 3D DNR
Privacy Mask 4 polygon programmable masks
Ethernet 1 × RJ45 10M/100M self-adaptive
On-Board Storage -F model: MicroSD/SDHC/SDXC up to 512 GB
Built-in Mic Yes
Reset Key -F model: Yes
Basic Events Motion detection (human/vehicle), tampering, exceptions
Event Linkage Memory card upload (-F), FTP upload, email, trigger capture
Power 12 VDC ± 25% (0.55 A, max 6.6 W) / PoE (IEEE 802.3af, Class 3, max 8 W)
Material Front cover: metal; body: plastic; bracket: plastic
Dimension (Camera) 69.8 × 67.9 × 172.9 mm (2.7" × 2.7" × 6.8")
Package Dimension 150 × 150 × 141 mm (5.91" × 5.91" × 5.55")
Weight 550 g (1.2 lb); with package: 800 g (1.8 lb)
Storage/Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F), Humidity ≤ 95% (non-condensing)
Languages English, Ukrainian
General Functions Heartbeat, anti-banding, mirror, password reset via email
Approvals (EMC) CE-EMC, RCM, ICES-003
Safety Standards IEC 62368-1, EN 62368-1, BIS: IS 13252
Environmental Standards CE-RoHS, WEEE, REACH
Protection IP67 (IEC 60529-2013)
