Specification
Thermal Module
Image Sensor VOx Uncooled Focal Plane Arrays
Resolution 26376 x 1280
Pixel Pitch 12 μm
NETD ≤ 35 mK (@25° C,F# = 1.0)
Focal Length 55 mm
Focus Mode Semi-auto & Manual
IFOV 0.22 mrad
Aperture F1.0
Field of View 360° × 17.5° (H × V)
Min. Focusing Distance 7.5 m
Image Effect
Target Coloration Supported in white hot and black hot mode
PTZ
Movement Range Pan: 360° Continuous Rotate; Tilt: From -25° to + 45°
Pan Speed 360° / 2.24s
Smart Function
VCA Support 3 VCA rule types (Intrusion, Region Entrance, and Region Exiting), up to
200 VCA rules
Fire Detection Dynamic fire point detection, up to 200 fire points detectable
Video and Audio
Main Stream 25 fps (4096 × 2160)
Sub-stream 25 fps (1024 × 1280)
Video Compression Main stream: H.265/H.264
Sub-stream: H.265/H.264
Network
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,
NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Network Storage MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS,
SMB/CIFS), auto network replenishment (ANR)
API ISAPI, HIKVISION SDK, Open Network Video Interface (Profile S, Profile G,
Profile T)
Simultaneous Live View Up to 20 channels
User/Host level Up to 32 users, 3 levels: Administrator, Operator, User
Security User authentication (ID and Password), MAC address binding, HTTPS
encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Client iVMS-4200, Hik-Connect, Hik-Central, HCP

Web Browser
Live view (plug-in allowed) : Internet Explorer 11
Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 +
Local service : Chrome 57.0+, Firefox 52.0 +
Interface
Alarm Input 1-ch inputs (0 to 5 VDC)
Alarm Output 1-ch relay outputs, alarm response actions configurable
Alarm Action SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
Communication Interface 1, RJ45 10 M/100 M/1000 M Self-adaptive Ethernet interface.
1, RS-485 interface
General
Menu Language
32 languages
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech,
Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish,
Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional
Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Power Supply 30 VDC~60 VDC, two-core terminal block
Power Consumption Max. 150 W
Working
Temperature/Humidity From -40°C to 60°C (-40°F to 140°F); Humidity: 90% ± 3% (no condensation)
Protection Level IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage
Transient Protection
Dimensions 408 mm × 310 mm × 407 mm
Weight Approx. 25kg (55.1 lb)
Detection Range Table
VCA Range for Humans 1000 m
VCA Range for Vehicles 3000 m
 Range Table
VCA Range
(Humans: 1.8 ×
0.5 m)
VCA Range
(Vehicles: 1.4 ×
4.0 m)
VCA Range
(Vessels: 20 × 5
m)
VCA Range (Drones:
45 × 45 cm)
Fire Detection
(Object: 2 × 2 m)
1 km 3 km 4 km 750 m 4.2 km
