View larger
HM-TD71C8-75/W
Thermal Panoramic Scanner
- 360° panoramic view within one camera
- 1280 × 1024 resolution 12 μm, VOx UFPA, NETD ≤ 25 mK (25 °C, F# = 1.0)
- Perimeter detection based on intelligent algorithm: intrusion, region entrance and exit
- Alarm linkage: Link other PT cameras to track moving targets when alarms triggered
Rating:
Be the first to write a review!
- 100% genuine, brand-new stock
- Delivered across Pakistan
- Showroom: TechnoCity, Karachi
- Bulk & corporate pricing on request
More info
HM-TD71C8-75/W overview
Hikvision HM-TD71C8-75/W - Thermal Panoramic Scanner.
Key Features
- 360° panoramic view within one camera
- 1280 × 1024 resolution 12 μm, VOx UFPA, NETD ≤ 25 mK (25 °C, F# = 1.0)
- Perimeter detection based on intelligent algorithm: intrusion, region entrance and exit
- Alarm linkage: Link other PT cameras to track moving targets when alarms triggered
Specifications
| Thermal Module | |
|---|---|
| Image Sensor | VOx Uncooled Focal Plane Arrays |
| Resolution | 39144 x 1280 |
| Pixel Pitch | 12 μm |
| NETD | ≤ 25 mK (@25° C,F# = 1) |
| Focal Length | 75 mm |
| Focus Mode | Semi-auto & Manual |
| IFOV | 0.16 mrad |
| Aperture | F1.0 |
| Field of View | 360° × 11.7° (H × V) |
| Min. Focusing Distance | 8 m |
| Image Effect | |
| Target Coloration | Supported in white hot and black hot mode |
| PTZ | |
| Movement Range | Pan: 360° Continuous Rotate; Tilt: From -25° to + 45° |
| Pan Speed | 360° / 3.36s |
| Smart Function | |
| VCA | Support 3 VCA rule types (Intrusion, Region Entrance, and Region Exiting), up to 200 VCA rules |
| Video and Audio | |
| Main Stream | 25 fps (4096 × 2160) |
| Sub-stream | 25 fps (1024 × 1280) |
| Video Compression | Main stream: H.265/H.264 Sub-stream: H.265/H.264 |
| Network | |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Network Storage | MicroSD/SDHC/SDXC card (up to 256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| API | ISAPI, HIKVISION SDK, Open Network Video Interface (Profile S, Profile G, Profile T) |
| Simultaneous Live View | Up to 20 channels |
| User/Host level | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security | User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering |
| Client | iVMS-4200, Hik-Connect, Hik-Central, HCP |
| Web Browser | Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 + |
| Interface | |
| Alarm Input | 1-ch inputs (0 to 5 VDC) |
| Alarm Output | 1-ch relay outputs, alarm response actions configurable |
| Alarm Action | SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage |
| Communication Interface | 1, RJ45 10 M/100 M/1000 M Self-adaptive Ethernet interface. 1, RS-485 interface |
| General | |
| Menu Language | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Power Supply | 30 VDC~60 VDC, two-core terminal block |
| Power Consumption | Max. 150 W |
| Working Temperature/Humidity | From -40°C to 60°C (-40°F to 140°F); Humidity: 90% ± 3% (no condensation) |
| Protection Level | IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimensions | 408 mm × 310 mm × 407 mm |
| Detection Range Table/Smart Function Range | |
| VCA Range for Humans | 1500 m |
| VCA Range for Vehicles | 4500 m |
Specifications as published by Hikvision for model HM-TD71C8-75/W.
