DS-2TD8167-150ZE2F/W(B)
DS-2TD8167-150ZE2F/W(B)
New product
Bispectral IP positioning system (thermal and visible) Audio Voice codecs G.711a/G.711u/G.722.1/G.726/MP2L2/PCM Camera Field of view (FOV) angle (thermal module) 20.56 x 16.51 ° Tilt angle -45 - 45 ° Lens angle of view, horizontal 32.13 ° Lens angle of view, vertical 18.4 ° Number of preset programs 300 Camera tilt control Yeah Panoramic camera control Yeah Minimum lighting 0.0005 lx
In Stock
WhatsApp
Rating:
Be the first to write a review!
More info
Product Information:
DS-2TD8167-150ZE2F/W(B) Features and Benefits
Features:
DS-2TD8167-150ZE2F/W(B) Description
Bispectral IP positioning system (thermal and visible)
Audio
| Voice codecs | G.711a/G.711u/G.722.1/G.726/MP2L2/PCM |
Camera
| Field of view (FOV) angle (thermal module) | 20.56 x 16.51 ° |
| Tilt angle | -45 - 45 ° |
| Lens angle of view, horizontal | 32.13 ° |
| Lens angle of view, vertical | 18.4 ° |
| Number of preset programs | 300 |
| Camera tilt control | Yeah |
| Panoramic camera control | Yeah |
| Minimum lighting | 0.0005 lx |
| Panoramic range (pan) | 0 - 360 ° |
| Tilt speed | 20 °/s |
| Shutter speed | 1 - 1/30000 Second s |
| Preset tilt speed | 200 °/s |
| Pan speed | 40 °/s |
| Pan preset speed | 240 °/s |
Design
| Protection code (IP) | IP66 |
| Product color | White |
| Protection | Waterproof |
Image sensor
| Progressive scanning | Yeah |
| Effective sensor resolution (thermal module) | 640 x 512 Pixels |
| Optical sensor size | 1/1.8 " |
| Sensor type | CMOS |
| Sensor type (thermal module) | Vanadium Oxide Uncooled Focal Plane Arrays |
Lens system
| Infrared spectral band | 8 - 14 µm |
| Zoom capacity | Yeah |
| Closest focusing distance | 3 m |
| Recognition distance (wide) | 3382 m |
| Detection distance (width) | 13529 m |
| Focal distance | 2.7-13.5 mm |
| Fixed focal length (thermal module) | 15 cm |
| Autofocus | Yeah |
| Identify distance (width) | 1691 m |
| Maximum opening number | 8.2 |
| Aperture number (thermal module) | 1.2 |
| Minimum opening number | 3.5 |
| Digital zoom | 16 x |
| Optical zoom | 62 x |
Management features
| Behavior analysis | Intrusion detection/Line crossing detection/Region entrance detection/Region exiting detection |
| Web-based management | Yeah |
Network
| Bluetooth | No |
| Ethernet LAN | Yeah |
| Client interoperability | iVMS-4200, Hik-Connect |
| User access level | Administrator/Operator/User |
| Number of simultaneous live viewing channels | 20 channels |
| Number of users | 32 user(s) |
| Supported network protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Quality of Service (QoS) support | Yeah |
| Ethernet interface type | Fast Ethernet |
| Live view | Yeah |
| Wi-Fi | No |
Night vision
| Night vision distance | 30 m |
Operational conditions
| Operating relative humidity (HH) | 0 - 95 % |
| Operating temperature (TT) | -40 - 65 °C |
Package dimensions
| Depth (package, cm) | 56.8 cm |
| Gross Weight (Package, kg) | 101 kg |
| Height (package,cm) | 60.8 cm |
| Width (package,cm) | 37.8 cm |
Packaging content
| Number of cameras | 1 |
Performance
| Wide Dynamic Range (WDR) | Yeah |
| PTZ control | Yeah |
| Alarm input/output | Yeah |
| Languages | Multi |
| IFOV (spatial resolution) | 0.57 mRad |
| Supported installation | Outdoor |
| Day/night mode | Yeah |
| Automatic patrol mode | Yeah |
| PTZ Modes | Preset point |
| Number of languages | 32 |
| Predefined points (presets) | Yeah |
| Dynamic range | 120 dB |
| Thermal sensitivity (NETD) | 35 mK |
| Connectivity technology | Wired |
Ports & interfaces
| Microphone input | Yeah |
| BNC output ports | 1 |
| Ethernet LAN ports (RJ-45) | 1 |
Power
| Power consumption (max.) | 220 W |
| DC output current | 5 A |
| Type of feed | DC |
| DC output voltage | 48 |
Product dimensions
| Net Weight (Product, kg) | 60 kg |
| Product Depth | 43.8 cm |
| Product Height | 66.83 cm |
| Product Width | 64.92 cm |
Security
| Security algorithms | EAP-MD5/EAP-TLS |
| Alarm input channels | 7 |
| Alarm output channels | 2 |
| HTTPS encryption | Yeah |
| Fire detection | Yeah |
| IP Address Filtering | Yeah |
| Temperature measurement accuracy | 8 °C |
| Password protection | Yeah |
| Temperature measuring range | -20 - 150 °C |
| Automatic Network Replenishment (ANR) | Yeah |
| Temperature sensor | Yeah |
Storage
| Integrated HDD | No |
| Integrated card reader | Yeah |
| Maximum memory card size | 256 GB |
| Compatible memory cards | MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
Technical details
| Suitable for outdoor use | Yeah |
| Output impedance | 600 Ω |
Vendor information
| Brand Name | Hikvision |
| Warranty | 5 Year/s |
Video
| Video compression formats | H.264/H.264+/H.265/H.265+/M-JPEG |
| Total megapixels | 2 MP |
| Noise reduction | Yeah |
| Maximum resolution | 1920 x 1080 Pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1280 x 960/1920 x 1080 (HD 1080)/352 x 288/384 x 288/640 x 480 (VGA)/704 x 576 |
| Noise reduction technology | 3D noise reduction |
| Gain control type | Car |
| Video streaming | Yeah |
| Frame rate | 30 pps |
Categories
| Main category | Surveillance and Security |
| Subcategory | Cameras |
| Subcategory | IP cameras |
